Details
Conveyor belts for coal
Mass flow measurement on conveyor belts
 |
|
Process data
Measuring task
Throughput measurement
Measuring point
Coal conveyor belt
Measuring range up to
2.80 m
Medium
Coal
Process temperature
-40 … +50 °C
Process pressure
0 … 0 bar
Special challenges
Dust exposure and fast belt speed, vibration
Application
For optimal quantity measurement of the coal being conveyed to the power plant or to the individual boilers, a continuous flow of material must be ensured. Throughput measurement on the conveyor belts accurately determines the amount of coal transported.
Your benefit
Reliable
Reliable mass flow measurement, unaffected by environmental influences
Cost effective
Long service life thanks to robust measuring system
User friendly
Simple installation on existing conveyors
Recommended Products
WEIGHTRAC 31
The radiation-based measuring system delivers reliable mass flow data, thus enabling optimization of coal throughput
- Maintenance-free through non-contact measurement
- Reliable mass flow measurement, unaffected by environmental influences
- Long service life thanks to non-contact measuring system
Measuring range - Distance
-
Measuring range - Pressure
-
Process temperature
-40 ... 60 °C
VEGASOURCE 31
The source container holds the radiation capsule and protects it from external influences
- Minimal space requirements and simple mounting
- Pneumatic opening and closing ensures high operational safety
- Dependable shielding also allows use without a control area
Ambient temperature
-20 ... 80 °C
