Refiner
Pressure measurement on the refiner
Process data
Measuring task
Pressure measurement
Measuring point
Pipeline
Measuring range up to
5 bar
Medium
Fibre suspension
Process temperature
+20 … +90 °C
Process pressure
+0.5 … +4 bar
Special challenges
Pressure shocks when drive starts, vibrations
Application
Refiners are used in paper production to grind up pulp. The main objective of the process is to impart certain properties to the pulp. Every refiner has a grinding set consisting of both fixed and rotating parts. The pressures at the input and output have to be measured for monitoring the loading and release of the grinding set as well as for display of performance.
Your benefit
Reliable
Reliable measured values for the load release
Cost effective
Reliable measurement protects against damage to the grinding set and avoids downtime
User friendly
Flush mounting transmitter for maintenance-free measurement
Recommended products
VEGABAR 82
Pressure measurement in the output pipe of the refiner
- Reliable measurement with ceramic CERTEC® measuring cell protects against damage and avoids production stoppages
- Maintenance-free self-cleaning effect through front-flush mounting
- Immune to pressure shocks, high temperatures and vibration, thanks to robust design of the sensor
Measuring range - Distance
-
Measuring range - Pressure
-1 ... 100 bar
Process temperature
-40 ... 150 °C
